1.Download link: 2.Run questasim-win64-10.2c.exe Next → Agree → Next → Yes -> Yes. Until the below window appears Click No • Run regassistuvm_4.3_win.exe to install UVM library. Click next Point to installed folder, click Next -> Install. 4.Cracking QuestaSim. • Copy the MentorKG.exe and patch_dll.bat trong folder crack after the installation of the Modelsim installation directory under the Win64 directory – c: questasim64_10.2c win64 -If it is running win7,XP directly runs patch_dll.bat.

After running will automatically replace the directory mgls.dll, then call MentorKG.exe (wait minutes) and automatically open file LICENSE.dat. You save as the generated file as LICENSE.dat in c: questasim64_10.2c win64 Right click on Computer ->Properties->Advanced system ( picture Above) -Choose Environment Variables tab-> Download variety show law the jungle sung jea lyrics. Click new -Then adding LM _LICENSE_FILE and c: questasim64_10.2c win64 license.dat Click OK – OK – OK //———————DONE——————//.

Best poser 8 content library download free download and full version 2016. The Questa® Advanced Simulator combines high performance and capacity simulation with unified advanced debug and functional coverage capabilities for the most complete native support of Verilog, SystemVerilog, VHDL, SystemC, SVA, UPF and UVM. The Questa Advanced Simulator is the core simulation.

Share This Post by Rich Edelman and Dave Rich Introduction The UVM is a derivative of OVM 2.1.1. It has similar use model, and is run in generally the same way.

One significant change is that the UVM requires a DPI compiled library in order to enable regular expression matching, backdoor access and other functionality. When running UVM based testbenches, we recommend using the built-in, pre-compiled UVM and DPI compiled libraries. This will remove the need to install any compilers or create a “build” environment. One other issue to mention if you are converting from OVM to UVM, and if you use stop_request() and/or global_stop_request(), then you will need to use the following plusarg, otherwise your testbench will end prematurely without awaiting your stop_request(). Vsim + UVM_USE_OVM_RUN_SEMANTIC +UVM_TESTNAME=hello Simulating with UVM Out-Of-The-Box with Questa The UVM base class libiraries can be used out of the box with Questa 10.0b or higher very easily.

There is no need to compile the SystemVerilog UVM package or the C DPI source code yourself. The Questa 10.0b release and every release afterwards contains a pre-compiled DPI library, as well as a pre-compiled UVM library. The only dependency is that your host system requires glibc-2.3.4 or later installed. Questa 10.0c Windows users only, please read thisabout the location of the DPI libraries. You can easily use these steps. Vsim hello Notice that we don’t have to specify +incdir+$(UVM_HOME)/src, $(UVM_HOME)/src/uvm_pkg.sv to vlog, or add a -sv_lib command to the vsim command to load the uvm_dpi shared object.

Controling UVM Versions Each release of Questa comes with multiple versions of the UVM pre-compiled and ready to load. By default, a fresh install of Questa will load the latest version of UVM that is available in the release. If an older version of UVM is needed, this version can be selected in one of two ways. Modify the modelsim.ini File Inside the modelsim.ini file, it contains a line which defines a library mapping for Questa.

That line is the mtiUvm line. It looks something like this. Vlib work vlog hello.sv -L $QUESTA_HOME/uvm-1.1a vsim hello -L $QUESTA_HOME/uvm-1.1a. If you are using some other platform, or you want to compile your own DPI library, please follow the directions below. If you use an earlier Questa installation, like 6.6d or 10.0, then you must supply the +incdir, and you must compile the UVM.

Cd $UVM_HOME/examples/simple/hello_world make BITS=64 -f Makefile.questa all Migration from OVM to UVM An OVM design can be migrated to UVM using a script. Many OVM designs can work without any hand coded changes or other intervention. It is a good idea to first get your design running on the latest version of, before starting the migration process. These designs can be converted from OVM to UVM using the distributed conversion script: cd $MY_TEST_BENCH $UVM_HOME/bin/ovm2uvm In certain cases hand coded changes might be required. Using the ovm2uvm script, you can run a “dry run” try and see what must be changed. There are many options to the script.
